100M/100M Compatible

Ethernet Speed

1

Ethernet Interface Number

RJ45

Ethernet Interface Type

1

Vehicle Interface Number

Molex 4Pin/(TE MATENET）/(H-MTD)

Vehicle Interface Type

DIP Switch/Auto Negotiation

Master/Slave

9~36V

Power Supply

12V

Standard Voltage

-20~85℃

Working Temperature

7W

Power Dissipation

0.24kg

Net Weight

106*90.5*34mm

Product Size

Aluminium Alloy

Shell Material

1 Channel /2 Channel

Channel Nnumber

:+/-30000 rpm

Speed Range

0~360^o

Angle Range

≤±0.2度

Angle Accuracy

5-inch capacitive touch screen

Display

2 sensors/4 sensors

Temperature Sensors Number

Signal attenuation, phase deviation, short circuit

Fault Injection Types

1~100

Polar Pair Range

Support

DC Bias Voltage Regulation

Support

Common Mode Output Voltage Regulation

0~2400mV（Default 1300）

Excitation Signal Amplitude

≤ 0.5us

Signal Delay

Eddy current  simulator test software

Software

Single channel/dual channel/triple channel

channels

-30000~30000 RPM

speed range

0~360^o

Electrical angle range

1~100

Polar logarithmic range

2K~50KHz

Excitation signal frequency

1~24V（peak-to-peak）

Excitation signal amplitude

30W

Maximum rated power

15W

Minimum rated power

18W

consumption

4.165kg

net weight

5kg

gross weight

208*341*87mm

Product size

45*30*15cm

Package size
