Number of corresponding ports

9

General specifications

Interface speed

NVMe：800MB/S; SATA：600MB/S

Capacity

Support all the largest capacity hard disks on the market

Operation mode

Stand-alone independent operation; Computer connection can monitor and browse the work log

Supported languages

Chinese & English

Monitor

Monochrome LCD display

LED Monochrome LCD display

Port red and green LED display

Operation keys

5 keys (▲/previous page, ▼/next page, OK/confirm, ESC/cancel, START/start)

Product function

Copy

Quick copy, full copy, percentage copy

Comparison

"Bit to bit" comparison of master and sub-disk data

Erasure

Quick erase, complete erase, DoD erase

Format

FAT16/ 32、exFAT

Advanced function

Computer connection

Real-time computer monitoring and work record storage

Imaging function

PC image making, image downloading and copying

Compatibility

File format

FAT16/32/64，exFAT，NTFS，EXT1/2/3/4

Hardware specifications

Work record preservation

Support local saving and network saving (customizable program can be accessed to the MES system of the factory)

Supported operating systems

Windows Full range，Lunix Full range，Mac OS,DOS

Directly compatible SSD

SATA Interface SSD，M.2 Interface PCI-E&SATA的SSD

Support MBR,GPT

YES

Size

Overall size：600mm*400mm*220mm

Input power supply

600W,12V/DC

Output power supply

DC +3.3V,+5V,+12V

Automatic power-off control

Support

Operating temperature range

-20°C ~ 85°C

Operating humidity range

20%~85%，Non-condensing

Storage humidity range

5%~95%，Non-condensing

Version

Download

V01

  Click to download

1.The new generation of NV series duplicators include three: NV-05SA, NV-10SA and NV-20SA
2.The old NV series copiers include NV-05M, NV-10SA and NV-20M
3.The new generation of NV series copying machine added asynchronous copy function and vertical plug interface

Q2:What is the service life of the vertical connector?

The vertical plug interface is designed by artificial mechanics and can support up to 10,000 times of plug and pull

Q3:What is the copy speed?

The copy speed of NV series duplicator can reach 800M/S

Q4:Can I support large-capacity SSD copy?

Sure

Q5:Can you copy IDE HDDs?

Sure.
NV-10SA拷贝机支持

Q6:Can I support HDD copy of U2 interface?

Sure.
All with SATA interface support HDD copy of U2 interface

Q7:The capacity of the master disk is different from that of the child disk. Can I copy it?

Sure.
The copy opportunity first analyzes whether the master data exceeds the range of the sub-disk. If not, the sub-disk can be copied even if the capacity of the sub-disk is smaller than that of the master< Br/>If it is a full disk copy, the copier does not analyze the data in advance, so you need to limit that the sub-disk must be larger than the master disk

Q8:Is the hard disk made by fast copy completely consistent with the master disk?

Yes.
The copier can completely copy. Even for fast data copy, the master will be analyzed first, and then the contents of the whole master or the system will be completely copied

Q9:Why does the copy fail?

1.First confirm whether the data capacity of the master disk exceeds the total capacity of the sub-disk. If so, make sure that the capacity of the sub-disk must be greater than the capacity of the master disk, at least 1MB.
2.The copy process shows failure. Please pay attention to whether the quality of the sub-disk or master disk has bad blocks. When a bad block is encountered during the copy process, the copy will fail.
3.If 1 and 2 are normal, contact our technical personnel for assistance

Q10:Why is copying slow?

In addition to being affected by the machine itself, the copy speed also depends on the read and write speed of the hard disk itself. Further troubleshooting is required:
  a.You can use the hard disk check tool to check whether the read and write speed of the hard disk is abnormal.
  b.Confirm whether all sub-disks are slow, or fix several sub-disks to slow down? If not all of them slow down, please check the slower hard disks and slots. Are the slots worn out and need to be updated?

Q11:How to ensure that the hard disk data is copied successfully?

In addition to the copy function, the copying machine also has the data comparison function. The system can turn on the comparison function. After the copy is completed, the system will automatically compare the data between the master and the sub-disk to ensure that the data copy is not lost or damaged

Q12: How many copying machines can be supported at most for serial simultaneous copying?

To ensure the copy speed and efficiency of the copying machine, it is recommended to connect up to 50 sets (1000 ports) in series

Q13: What is the difference between fast copy and full-area copy?

Fast copy: only copy the format data area supported by the system, avoiding blank areas, so it can greatly reduce the copy time and improve the copy efficiency. When selecting fast copy, the copy opportunity will analyze the data first. If it is found that the actual target card cannot hold all the parent data, the copy opportunity will directly turn on the red light< Br/>Full copy: regardless of any format, file size, the copying machine does not analyze, but directly copies the track to track, which takes a long time to copy.

Q14: Why does the red light come on immediately after I insert the card and press the copy button?

Please check whether your parent source data is larger than the child source data, or the parent source data location has exceeded the child source space< Br/>If you copy NTFS format, please confirm that the capacity of your parent source Flash must be smaller than that of the child source< Br/>Please put your parent source on your PC to see if it can be read normally< Br/>If you are copying the SD card, please confirm whether the SD card is locked.
